A simple GUI tool for antenna array analysis.
Only support linear arrays now
Usage
- Download the corresponded release based on your system
- Run
array_analysis
Feedback
Please submit bug reports and any suggestions here.
Related Posts
Software
Tx-Line Calculator
A transmission line calculator for RF/microwave engineers. Supported transmission lines: Microstrip Line Coupled Microstrip Line Stripline Coupled Stripline Coplanar Waveguide Grounded Coplanar Waveguide Coaxial
4 Comments
邓飞杨 · April 2, 2021 at 6:12 am
Mr. Peng, I want to adjust the wavelength parameters more flexibly. For example, 0.8 lambda or 1.2 lambda. How can I modify your program to get this funcation. Thank you very much!
Zhengyu Peng · April 2, 2021 at 8:59 am
Type in the number directly.
xuzhimin · April 10, 2024 at 10:43 pm
the unit of Lamda is mitre？
xuzhimin · April 10, 2024 at 10:47 pm
the input only the half or number of wavelength
